EL2211 Series

Product Description

For Quotation, please click the Contact Us button below.

EL2211-X1Z   (X and Z  should be choose for options )

10/100/1000BASE-TX to 1000BASE-SX/LX/BX Media Converter

Gigabit Connectivity
• Auto 10/100/1000BASE-TX and 1000BASE-SX/LX/BX Ethernet
• transmission conversion
• 1000Mbps Full duplex, 10/100Mbps Full/Half duplex

Link-Fault-Pass-Through (LFPT)
• LFPT function lets network operators be aware of network
• connection status
•  If a link fails, the LFPT function will notify the connected
• device and disable the connection

Optional Chassis System
• Supports wall mounting or EtherWAN's EMC1600 chassis
• system for easy group installation with power redundancy

Overview

The EL2211 Series provides media conversion between 10/100/1000BASE-T (X) and 1000BASE-SX/LX/BX Fiber.
Through DIP switch selection, Link-Fault-Pass-Through (LFPT) function can be active or disabled. With Gigabit transmission rate, the EL2211 supports Jumbo Frame up to 9K bytes.

The EL2211 is the ideal media converter for enterprise environments.

Notice:

EL2211-X1Z

(X) and (Z)  should be choose by following Gigabit Port Options (X) and  Power Adapter Options (Z).
